MIL-DTL-62006C(AT)
a. First article inspection (see 4.1.1).
b. Conformance inspection (see 4.1.2).
c. Acceptance tests (see 4.1.3).
4.1.1 First article inspection. Unless otherwise specified (see 6.2 and 6.3), first article
inspection shall be performed on three cooler assemblies or cores. The inspection shall include all
the examinations and tests as specified in table III.
4.1.1.1 Initial production inspection. Unless otherwise specified (see 6.2), two cooler
assemblies or cores from the first 100 cooler assemblies or cores produced shall be selected for
initial production testing. This inspection shall include the verifications as specified in 4.3.3,
4.4.1, and 4.4.2.
TABLE III. Verification methods.
Require-
Verifica-
Require-
Verifica-
Title
ments
tion
Title
ments
tion
3.2
4.3.3
3.5
4.5
Design and construction
Support and ownership
Welding, brazing, and
3.2.1
4.3.3.1
requirements
soldering
Safety
3.5.1
4.5.1
3.3
4.3.3
Contamination resistance
3.5.2
4.5.2
Materials
Corrosion resistance
3.3.1
4.3.3.2
Identification marking
3.5.3
4.5.3
3.4
4.4
3.6
4.6
Operating requirements
Operating environment
Leakage
3.4.1
4.4.1
requirements
Heat rejection
3.4.2
4.4.2
Vibration
3.6
4.6
4.1.2 Conformance inspection. Conformance inspection shall include the verifications
listed in table III as specified in the contract (see 6.2 and 6.4).
4.1.3 Acceptance tests (100 percent (%)). Each cooler assembly and/or core shall be
subjected to and pass the tests as specified in 4.4.1.
4.1.4 Sampling. The sampling plan shall be as specified in the contract (see 6.2).
4.2 Order of inspection. The inspection sequence may be in any order, except that the
verifications specified in 4.3.3.1 and 4.6 shall precede the testing of all the operating requirements
(see 4.4).
4.3 Verification methods. The types of verification methods included in this section are
visual inspection, measurement, sample tests, full-scale demonstration tests, simulation, modeling,
engineering evaluation, component properties analysis, and similarity to previously approved or
previous qualified designs.
6
