MIL-PRF-45085 Oil Cooler Assembly: Engine And TransmissionThis specification covers one type of oil cooler assembly for cooling engine and transmission oils \(see 6.1\) and is comprised of two engine oil cooler core assemblies and one transmission oil cooler assembly.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12


MIL-PRF-45085D
To Engine
From Transmission
Air
Flow
CORE ARRANGEMENT A. ENGINE & TRANSMISSION (DRW.8690239)
To Engine
Air
Flow
From Engine
CORE ARRANGEMENT B. ENGINE CORE (DRW.7356770)
To Transmission
Air
Flow
From Transmission
CORE ARRANGEMENT C. TRANSMISSION CORE (DRW.7356769)
NOTE: All tests made with air flowing through three cores (two engine cores and one
transmission core).
FIGURE 1. Flow circuit of core arrangements.
